Approaches to pattern matching in compilers

Git revision #fee2a364
Modified at 26. July 2025 14:20

Written by alex_s168

Introduction

Common use cases for pattern matching in compilers:

• "peephole optimizations": the most common kind of optimization in compilers. They find a short sequence of code and replace it with some other code. For example replacing x & (1 << b) with a bit test operation.
• finding a sequence of operations for complex optimization passes to operate on: advanced compilers have complex optimizations that can't really be performed with simple IR operation replacements, and instead require complex logic. Patterns are used here to find operation sequences where those optimizations are applicable, and also to extract details inside that sequence.
• code generation: converting the IR to machine code / VM bytecode. A compiler needs to find operations (or sequences of operations) inside the IR, and "replace" them with machine code.

Simplest Approach

The only advantage to this approach is that it doesn't require a complex pattern matching system.

I only recommend doing this for small compiler toy projects.

Disadvantages

Some (but not all):

• debugging pattern match rules can be hard
• IR rewrites need to be tracked manually (for debugging)
• source locations and debug information also need to be tracked manually, which often isn't implemented very well.
• verbose and barely readable pattern matching code
• overall error-prone

I myself did pattern matching this way in my old compiler backend, and I speak from experience when I say that this approach sucks (in most cases).

Pattern Matching DSLs

I will put this into the category of "structured pattern matching".

An example is Cranelift's ISLE DSL:

;; x ^ x == 0.
(rule (simplify (bxor (ty_int ty) x x))
      (subsume (iconst_u ty 0)))

Another example is tinygrad's pattern system:

(UPat(Ops.AND, src=(
   UPat.var("x"),
   UPat(Ops.SHL, src=(
     UPat.const(1),
     UPat.var("b")))),
 lambda x,b: UOp(Ops.BIT_TEST, src=(x, b)))

Fun fact: tinygrad actually decompiles the python code inside the second element of the pair, and runs multiple optimization passes on that.

Advantages

• debugging and tracking of rewrites, source locations, and debug information can be done properly
• patterns themselves can be inspected and modified programmatically.
• they are easier to use and read than manual pattern matching in the source code.

There is however an even better alternative:

Pattern Matching Dialects

The main example of this is MLIR, with the pdl and the transform dialects. Sadly few projects/people use these dialects, and instead do pattern matching in C++ code. Probably because the dialects aren't documented very well.

What are compiler dialects?

Each dialect either represents specific kinds of operations, like arithmetic operations, or a specific backend's/frontend's operations, such as the llvm, emitc, and the spirv dialects in MLIR.

Dialects commonly contain operations, data types, as well as optimization and dialect conversion passes.

Examples

pdl.pattern @replace_addi_with_my_add : benefit(1) {
  %arg0 = pdl.operand
  %arg1 = pdl.operand
  %op = pdl.operation "arith.addi"(%arg0, %arg1)

  pdl.rewrite %op {
    %new_op = pdl.operation "my.add"(%arg0, %arg1) -> (%op)
    pdl.replace %op with %new_op
  }
}

Advantages

• the pattern matching infrastructure can optimize it's own patterns: The compiler can operate on patterns and rewrite rules like they are normal operations. This removes the need for special infrastructure regarding pattern matching DSLs.
• the compiler could AOT compile patterns
• the compiler could optimize, analyze, and combine patterns to reduce compile time.
• IR (de-)serialization infrastructure in the compiler can also be used to exchange peephole optimizations.
• bragging rights: your compiler represents its patterns in it's own IR

Combining with a DSL

The advantage of this over just having a rewrite dialect is that it makes patterns even more readable (and maintainable!)

egg

egg is a IR pattern matching and transformation library that uses E-Graphs to magically solve (almost) all problems regarding IR pattern matching.

Even though egg solves most problems, I still recommend using a pattern matching dialect, especially in multi-level compilers, to be more flexible, and have more future-proof pattern matching, if for example there suddenly is a better alternative to egg, or you decide that you want to match some complex patterns manually.

A problem with using egg in combination with pattern matching dialects is that it might be harder to write the code to convert the pattern matching dialect to egg patterns.

Additionally, some more complex transformations (not the matches) can't always be directly converted to egg transformations (depending on the feature set provided by the transformation dialect), but that can be solved by using a custom egg::Applier

More Advantages of Structured Pattern Matching

Smart Pattern Matchers

There are other ways to speed up the pattern matching and rewrite process using this too.

A better solution is to associate a set of implementations with the bit test operation, and make the compiler automatically reverse those to generate the best implementation (in the instruction selector for example).

Implementing pattern/transformation reversion can be challenging however, but it provides many benefits, and all "big" compilers should definitely do this, in my opinion.

Runtime Library

The implementation of those functions should also use that pattern matching dialect. This allows your backend to detect code written by users with a similar implementation as in the runtime library, giving you some additional optimizations for free.

I don't think any compiler currently does this either.

Problems with Pattern Matching

As an example, consider these three patterns:

;; A
(add x:Const y) => (add y x)

;; B
(sub (add x y:Const) z:Const) => (lea x y (const_neg z))

;; C
(add x 1) => (inc x)

Now what should the compiler do when it sees this:

(sub (add 5 1) 2)

All three patterns would match:

;; apply A
(sub (add 5 1) 2) => (sub (add 1 5) 2)
;; only B applies now
(sub (add 1 5) 2) => (lea 1 5 (const_neg 2))
;; nothing applies anymore

;; alternatively apply B
(sub (add 5 1) 2) => (lea 5 1 (const_neg 2))
;; nothing applies anymore

;; atlernatively apply C
(sub (add 5 1) 2) => (sub (inc 5) 2)
;; nothing applies anymore

Now which of those transformations should be performed?

This is not as easy to solve as it seems, especially in the context of instruction selection (specifically scheduling), where the performance on processors depends on a sequence of instructions, instead of just a single instruction.

Superscalar CPUs

As a simple, unrealistic example, let's imagine a CPU (core) that has one bit operations execution unit, and two ALU execution units / ports.
This means that the CPU can execute two instructions in the ALU unit and one instruction in the bit ops unit at the same time.

One might think that always optimizing a & (1 << b) to a bit test operation is good for performance. But in this example, that is not the case.

If we have a function that does a lot of bitwise operations next to each other, and the compiler replaces all bit tests with bit test operations, suddenly all operations depend on the bit ops unit, which means that instead of executing 3 instructions at a time (ignoring pipelining), the CPU can only execute one instruction at a time.

This shows that we won't know if an optimization is actually good, until we are at a late point in the compilation process where we can simulate the CPU's instruction scheduling.

This does not only apply to instruction selection, but also to more higher-level optimizations, such as loop and control flow related optimizations.

Conclusion

Someone wanted me to insert a takeaway here, but I won't.

PS: I'll hunt down everyone who still decides to do pattern matching in their compiler source after reading this article.
